1. Produced of high quality steel，carburize to surface hardness: HRC58～62
2. Parallelism 0.005mm/100mm, squareness 0.005mm
3. Quickly to clamp and easy to operate
4. Used for precision measurement and inspection precision grinding, EDM and wire-cutting machine
5.Guarantee high accuracy in any position
Product brief description
Product parameters table
| Model | B | H | Smax | L | N.W.(kg) |
| mm | mm | mm | mm | ||
| QGG50 | 50 | 25 | 65 | 155 | 3 |
| QGG60 | 60 | 25 | 55 | 110 | 2.4 |
| QGG63 | 63 | 32 | 85 | 190 | 3.8 |
| QGG73 | 73 | 35 | 100 | 210 | 5 |
| QGG80 | 80 | 40 | 100 | 220 | 6.5 |
| QGG88 | 88 | 40 | 125 | 250 | 11 |
| QGG100 | 100 | 45 | 125 | 260 | 13 |
| QGG125 | 125 | 50 | 160 | 300 | 19.5 |
| QGG125A | 125 | 50 | 210 | 350 | 23 |
| QGG150 | 150 | 50 | 175 | 315 | 23.8 |
