1. Produced of high quality steel，carburize to surface hardness: HRC58～62
2. Parallelism 0.005mm/100mm, squareness 0.005mm
3. Quickly to clamp and easy to operate
4. Used for precision measurement and inspection precision grinding, EDM and wire-cutting machine
5.Guarantee high accuracy in any position
Product brief description
1. Produced of high quality steel，carburize to surface hardness: HRC58～62
2. Parallelism 0.005mm/100mm, squareness 0.005mm
3. Quickly to clamp and easy to operate
4. Used for precision measurement and inspection precision grinding, EDM and wire-cutting machine
5.Guarantee high accuracy in any position
Product specifications
| Model | B | H | Smax | L | Clamping force |
| mm | mm | mm | mm | kg | |
| GT100-I | 100 | 35 | 100 | 270 | 3000 |
| GT125-I | 125 | 40 | 150 | 345 | 3000 |
| GT150A-I | 150 | 50 | 200 | 420 | 5000 |
| GT150B-I | 150 | 50 | 300 | 520 | 5000 |
| GT150C-I | 175 | 50 | 400 | 620 | 5000 |
| GT175A-I | 175 | 58 | 200 | 455 | 6000 |
| GT175B-I | 175 | 58 | 300 | 555 | 6000 |
| GT175C-I | 175 | 58 | 400 | 655 | 6000 |
| GT175D-I | 175 | 58 | 500 | 755 | 6000 |
| GT175E-I | 175 | 58 | 600 | 855 | 6000 |
| GT200A-I | 200 | 70 | 200 | 495 | 10000 |
| GT200B-I | 200 | 70 | 300 | 595 | 10000 |
| GT200C-I | 200 | 70 | 400 | 695 | 10000 |
| GT200D-I | 200 | 70 | 500 | 795 | 10000 |
| GT200E-I | 200 | 70 | 600 | 895 | 10000 |
| GT300A-I | 300 | 80 | 200 | 535 | 12000 |
| GT300B-I | 300 | 80 | 300 | 635 | 12000 |
| GT300C-I | 300 | 80 | 400 | 735 | 12000 |
| GT300D-I | 300 | 80 | 500 | 835 | 12000 |
| GT300E-I | 300 | 80 | 600 | 935 | 12000 |
| GT300F-I | 300 | 80 | 700 | 1035 | 12000 |
| GT300G-I | 300 | 80 | 800 | 1135 | 12000 |
