5C collet set

These collets are an alternative to the collet chuck system.

Each 5C collet is held by the machine drawbar.

As the collet is drawn into the quill it firmly clamps around the end mill/slot drill shank.

Both plain and threaded shank cutters can be used.

5C collets do not overhang which allows max.capacity between the spindle and table.

5C collets can be purchased by sets and are therefore very affordable.

Introduction

Product brief

These collets are an alternative to the collet chuck system.
Each 5C collet is held by the machine drawbar.
As the collet is drawn into the quill it firmly clamps around the end mill/slot drill shank.
Both plain and threaded shank cutters can be used.
5C collets do not overhang which allows max.capacity between the spindle and table.
5C collets can be purchased by sets and are therefore very affordable.

Product Description

Features

5C collet sets are manufactured to exacting standards from special steel. Heat treated to assure accuracy and durability. 5C Collets offer a through-capacity up to and including 1-1/8" round. 5C collets include precision internal threads for positive stops. The sets are attractively priced and packaged in quantities that will outfit your machine nicely.We can flexibly match the size and quantity of the 5C collets in the set according to customer requirements.

Product parameters

Type	Clamping range	Collet
5C-8PCS	1/8"- 1"	1/8",1/4",3/8",1/2",5/8",3/4 ",7/8",1 "
5C-14PCS	3-25mm	Φ3,Φ4,Φ5,Φ6,Φ8,Φ10,Φ12,Φ14,Φ15,Φ16,Φ18,Φ20,Φ22,Φ25
5C-15PCS	1/8"- 1"	1/8",3/16",1/4",5/16",3/8",7/16",1/2",9/16",5/8",11/16",3/4 ",13/16 ",7/8",15/16",1 "
5C-18PCS	1/16"-1-1/8"	1/16",1/8",3/16",1/4",5/16",3/8",7/16",1/2",9/16",5/8",11/16",3/4 ",13/16 ",7/8",15/16",1 ",1 -1/16",1 -1/8"
5C-24PCS	3-26mm	Φ3,Φ4,Φ5,Φ6,Φ7,Φ8,Φ9,Φ10,Φ11,Φ12,Φ13,Φ14,Φ15,Φ16,Φ17,Φ18,Φ19,Φ20,Φ21,Φ22,Φ23,Φ24,Φ25,Φ26
5C-29PCS	3-26mm	Φ3,Φ4,Φ5,Φ5.5,Φ6,Φ7,Φ8,Φ9,Φ9.5,Φ10,Φ11,Φ12,Φ12.5,Φ13,Φ13.5,Φ14,Φ15, Φ16,Φ17,Φ18,Φ19,Φ20,Φ20.5,Φ21,Φ22,Φ23,Φ24,Φ25,Φ26
	1/8"- 1"	1/8",5/32",3/16",7/32",1/4",9/32",5/16",11/32",3/8",13/32",7/16",15/32",
		1/2",17/32",9/16",19/32",5/8",21/32",11/16",23/32",3/4",25/32",13/16",
		27/32",7/8",29/32",15/16",31/32",1"
5C-57PCS	1/8"- 1"	1/8",9/64",5/32",11/64",3/16",13/64",7/32",15/64",1/4",17/64",9/32",19/64",5/16",21/64", 11/32",23/64",3/8",25/64",13/32",27/64",7/16",29/64",15/32",31/64",1/2",33/64", 17/32",35/64",9/16",37/64",19/32",39/64",5/8",41/64",21/32",43/64",11/16",45/64",23/32",47/64",3/4", 49/64",25/32",51/64"13/16",53/64",27/32",55/64",7/8",57/64",29/32",59/64",15/16",61/64",31/32",63/64",1"
